Nº 01 Automatic cone winder SAVIO ORION L , with Nº 56 heads ,

– manual bobbin feeding , magazine revolver type ,

– pitch 6″ (152 mm) , conicity 4°20′ , drum diam 94 mm. 2 turns asymmetric step ,

– automatic bobbins doffing ( by n. 02 trolley ) ,

– double centralized empty cones feeding ,

– package conveyor belt , split for unloading n. 03 lots ,

– Nº 03 pneumatic control panel , to split yarn tension for n. 03 lots ( 24/16/16 ) ,

– double tubes unload belt , one towards the head , one towards the tail of the machine ,

– yarn stretcher + waxing device on n. 16 heads , yarn stretcher on n. 40 heads ,

– ” Tensor ”  sensor device  to control by Computer the constant density winding process ,

– automatic joint yarn Splicer Mesdan mod. 690 ,

– Computer to set speed , yarn length on package and to control/monitor all the winding process ,

– electronic yarn  clearers Loepfe Zenit YM C , equipped with foreign fibers chanel ,

– Magitex Blower ,

– Lightening along the machine ,

– Year 2005 , serial number 341.159.05 .

N. 02 Vigoureux Dyeing / Printing tops sliver machine , brand Sant’Andrea , with comb head ,

16 coupling , n. 04 different printing drums included .

N. 02 fancy yarn twisting machine PA-FA mod.  NTF 2 , with n. 30 heads each /1 machine ,
hollow spindle , double independent drafting lines , feeding from tapers  by cans , or slivers by Finisher / Flyer bobbins  , delivery on tubes H. 450 mm. , ring diameter 140 mm. , Electronic panel to set fancy effects, , Y.O.C. : 1 x 2005 , 1 x 2006 .

N. 01 Bale Opener TECNOMECCANICA BIELLESE ,

model ABL 1600 , Year 2001 ,W.W. 1.600 MM. , tape length 4.500 mm.

Nº 01 Opener Carding Willow machine , brand ROLANDO , w.w.  1.600 ;

Machine refurbished , equipped with New Electric Switchboard , 380V. 50 Hz ;

N. 01 Automatic winder for continuous shrinkage and high bulking yarns ,

SAVIO ESPERO VOLUFIL , year 2010 , with n.  45 heads

Nr. 01 Double twisting (2×1) frame SAVIO GEMINIS mod. 242 C ,
with Nº 220 spindles , double drive , two independent frames ,
package lifting to yarn breaks ,
feeding hight 8 “ inch , basket for bobbin diam. 185 mm. ,
delivery 6’’ ( 152 mm. ) x 4º20′ ,
pneumatic yarn thread in ,
blower Electrojet ,
inverter to speed set ,
V 380/50-60 hz ,
Year 1996.
Excellent condition of maintenance

N. 01 Hank to Cone Winder FADIS , Mod. MATRIX D,
n. 30 independent spindles, pitch 6 / 8″ (152 / 200 mm),
hank-holding for hanks weighing up to 2 Kg., waxing device,
electronic positive yarn over-feeder, electronic yarn guided winding system controlled by a step motor piloted and controlled by one inverter for each single spindle, year 2016

N. 01 Cabinet Hanks dyeing  LORIS BELLINI , model APPC 125 , Year 2017 , capacity 160/190 Kg.

( depending on the fibers and count yarns ) , low liquor ratio control system , under static pressure up to 110º , bar 0,4 ,dyeing kitchen with double tanks , expansion and colour introduction vessels .Machine complete with : N. 02 extractable hanks holder basket with proper trolley ,n. 02 sets of hanks sticks holder , electric panel with PLC control panel to set dyeing parameters  , valves , main pump , etc

n.1 LAFER fringing ( flecadora para frazadas )
type FRV 3000
working width 3.300 mm.
year 1999

N.01  Gill Box Cognetex , mod. SC 400 11 VA with autoleveller ,
feeding creel 10 positions by cans ,delivery  1 sliver in 1 can  700 x 1000 with automatic doffing ;
N.01  Gill Box Cognetex , mod. SC 400 22 V  ,
feeding creel 10 positions by cans ,
delivery  2 slivers in 2 cans  700 x 1000 with automatic doffing ;
N.01  Gill Box Cognetex , mod. SC 400 22 V  ,
feeding creel 10 positions by cans ,
delivery  2 slivers in 2 cans  700 x 1000 with automatic doffing ;

N. 01 Rebreaker Blender drawing frame COGNETEX  mod. SMC 400 , 11V ,
comb head with rotary flanges , N. 104 pinned faller bars with 4 pins/CM ,
n. 04 defelting zones ( with nº 5 draft rubber cylinders )  ,
delivery 1 sliver in 1 can 700 x 1000 with automatic doffing ;
feeding creel :
Option 1 ) = 16 coupling by cans
Option 2 ) = 24 coupling by bobbins

N. 01 Spinning frame Cognetex FTC 9 L ,
504 spindles , gauge 90 mm. ,
ring diam. 70 mm. , tube H. 300 mm. ,  draft SKF PK  1601 ,
double frame , single drive , tangencial spindles drive belt ,
manual  spools doffing ,  Magitex blower ,
Inverter to speed set ,
yoc 1989 ;

N. 1 Ring Spinning and Fancy frame , PA-FA ,  mod. EXPO 80  ,
with nr.  48 spindles  , suitable to produce effect yarns in medium / coarse counts , in new combinations of colors in a wide range , for both regular and or fancy yarns , double independent draft to permit the entrance of separate roving ( machine can be feeding by one or two slivers )  , computer to set machine data and adjustment processing parameters , feeding by external feeding creel  ( by slivers from Flyer or Finisher bobbins or  by tapers from cans )   ,ring diameter 140 mm. ( like new ) ,delivery on tubes h. 600 mm. ,year o.c. 2005 ,

N. 01 SEYDEL 870  stretch breaker tow to tops ,
year manufacture 1992 ,
heater plates, csr steamer,
delivery 700 x 1000 mm.  Can coiler ,

N. 1 Rebreaker Blender drawing frame N.S.C. Schlumberger , GC12 RL5,  year 1988 ,comb head with chain drive , with n. 144 combs , n. 04 defelting zones – nº 5 draft rubber cylinders , feeding creel  32 coupling by cans ;

Linked with : N. 01 ST. Eloi bumps press 400 mm. , year 1988 , with automatic knotting .

Nº 01 Cone to cone winder SAVIO ORION ” RL ” , with Nº 60 heads ,
– feeding by cone with automatic cone change ( 240 mm. diameter max ) ,
– pitch 6″ (152 mm) , conicity 4º 20′ , drum diam 94 mm. 2 turns asymmetric step ,
– 2 section yarn stretcher + waxing device ,
– four pneumatic control panel ( to split yarn tension 24/16/8/8/ position ) ,
– automatic joint yarn Splicer Mesdan mod. 690 L or Fisherman 410 B ,
– Nº 2 trolley automatic bobbins doffing ,
– Nº 2 automatic magazine cone reserve ,
– Computer to set speed , yarn length on package and to control/monitor all the winding process ,
– electronic yarn clearers Loepfe Zenit YM F ,
– Magitex Blower ,
– Lightening along the machine ,
– Year 2005 .

N. 04 Autoconer SCHLAFHORST , 338 Typ D , n. 30 Heads ,
year : 1 x 2004 , 2 x 2005 , 1 x 2006 ;
delivery on 6″ ( 152 mm. ) taper 5°57′, drums 2 assymetrical turns ,
automatic package doffing by 1 trolley ,
cones reserve with individual cradles each head ,
automatic spools feeding ( spools up to H 350 mm. ), ring diam. up to 75 mm.,
3 preparation cops station ,
electronic clearers Loepfe Zenit ( foreign fiber control ) ,
Thermo Splicer ,
waxing device ,
Yarn tension sensor (autotense) ,
Informator to set data ,
travelling blower ;

Nonwoven needle punching small plant , composed by :

N. 02 Cutting machines Gamba , ww. 1000 mm. ,

N. 01 Tearing grinding machine Becherini , ww. 1500 mm. ,

N. 01 Carding machine Bonino , ww. 2800 mm. , twin doffer , linked with needle punching machine ;

N 02 N.S.C. ERA Combers , year 2012 , exit 700 x 1000 mm. ,

feeding 24 coupling by cans , machines in good condition of maintenance ;

Nr. 1 rag-grinding tearing machine ,  Brand  : GAMBA  ( Biella Italy )  ,

w.w. 2.000 mm. , nr. 5 tearing cylinders and nr. 5 condensers  ,

with  automatic feeding Silo  , fibers discharging by cyclone  ,

complete with suction dust device , year of. C. 1992 .

N. 01 Integrated Drawing frame N.S.C. GC 15 , year 2002 ,

with defelting zone , feeding creel 24 coupling ,

delivery  2 slivers / 2  bobbins , autodoffing .

N. 02 Karl Mayer winder , Model . RC10NG ,
with 20 heads each / 1 machine ,
manual spools feeding , Ypsilon type round magazine with 05 position ,
spools from H 450 to H 600 mm. ,
delivery cones on 10″ ( 270 mm. ) ,
drums 2 symmetrical turns ,
automatic package doffing ,
cones reserve with individual cradles each head ,
electronic clearers Uster MK46 count range NM 0,5 to NM 13 ,
Splicer ,
travelling blower ,
year 1993 ,
machines fully refurbished
